Ansible Configuration on AWS using Terraform

πŸš€ Overview:

In modern cloud environments, managing infrastructure efficiently and securely is crucial for ensuring smooth operations and maximizing resource utilization. Ansible, a powerful automation tool, provides a flexible and scalable solution for configuration management, provisioning, and orchestration of infrastructure on AWS. By leveraging Ansible, organizations can streamline deployment processes, enforce consistent configurations, and accelerate time-to-market for their applications. The primary objective of this project is to design and deploy a controller Linux server, two Linux client servers and two Ubuntu client server on AWS. Then we will be writing a playbook that will be installing and configuring apache on all clients servers. The playbook will include also git installation.

πŸ”§ Problem Statement

Terraform is an IaC software tool that provides a consistent command line interface (CLI) workflow to manage hundreds of cloud services. Terraform codifies cloud APIs into declarative configuration files. In this specific case you need to create 5 EC2 instances such as 1 Amazon Linux 2 that will call controller, then two clients or nodes with Amazon Linux 2 and 2 other with Ubuntu. Terraform will automatically use the configuration files to provide those resources and the user data placed in te controller will install Ansible on it. We will then use the Ansible playbook to update all hosts, install Apache and Git then copy te index.html file on each hosts. This deployment will provide all necessary tools and needed elements avoiding us to use the console. All process of working on nodes will be automate that will ensuring consistency and reducing human error.

πŸ’½ Techonology Stack

We will be using:

  • EC2: AWS EC2

  • Ansible Playbook: Ansible

  • File Configuration: Terraform

πŸ“Œ Architecture Diagram

🌟 Project Requirements

Before you get started, make sure you have the following prerequisites in place:

  • Terraform installed on your local machine.

  • AWS IAM credentials configured in your text editor. In this case we will use VSCODE.

  • Git installed on your local machine and Github account set up Github

  • Git for cloning the repository.

You must know and understand:

  • Ansible playbook: is a YAML file that defines a series of tasks to be executed on remote hosts.

  • Apache web Server: The Apache HTTP Server, commonly referred to as Apache, is an open-source web server software developed and maintained by the Apache Software Foundation. It is one of the most widely used web server applications globally and powers a significant portion of websites on the internet.

  • Git: is a distributed version control system (VCS) that is widely used for tracking changes in source code during software development.

You must also know Terraform workflow

πŸ“‹ Table of Contents

I - Terraform Configuration files

Step 1: Provider Configuration

Step 2: Variables Configuration

Step 3: Instances Configuration

Step 4: Output Configuration

II - Instructions of Deployment

Step 1: Clone Repository

Step 2: Initialize Folder

Step 3: Format Files

Step 4: Validate Files

Step 5: Plan

Step 6: Apply

Step 7: Review of Resources

Step 8: Connect to the Controller

Step 9: Connect to all Hosts

Step 10: Generate & Copy Key Pair

Step 11: Configuration on Controller

Step 12: Run Ansible Command

Step 13: Review of Changes

Step 14: Destroy

✨Terraform Configuration files

You need to write different files generating resources

Step 1: Provider Configuration

Here we declare our cloud provider and we specify the region where we will be launching resources

Step 2: Variables Configuration

This is where we declare all variables and their value. It includes

  • Variables: List of element that can vary or change. They can be reuse values throughout our code without repeating ourselves and help make the code dynamic

  • values: values attributed to each variables.

Reminder: Never push " terraform.tfvars" file on Github

We have

Step 3: Instances Configuration

This is where you create all fives instances. The controller and two other nodes will be running on Amazon linux 2 and two other on Ubuntu. We will open port 80 (http) and 22 (ssh) on the security group.

Step 4: Output Configuration

Know as Output Value : it is a convenient way to get useful information about your infrastructure printed on the CLI. It is showing the ARN, name or ID of a resource. In this case we are bringing out the DNS name of the web application Load balancer.

πŸ’Ό Instructions of Deployment

Follow these steps to deploy the architecture:

Step 1: Clone Repository

Clone the repository in your local machine using the command "git clone"

   git clone https://github.com/Joebaho/Joebaho-Cloud-Platform/blob/main/site/ansible-terraform-on-aws
Step 2: Initialize Folder

Initialize the folder containing configuration files that were clone to Terraform and apply the configuration by typing the following command

   terraform init

You must see this image

Step 3: Format Files

Apply any changes on files and Review the changes and confirm the good format with command:

   terraform fmt
Step 4: Validate Files

Ensure that every files are syntactically valid and ready to go with the command:

   terraform validate

If everything is good you will have something like this

Step 5: Plan

Create an execution plan to provide the achievement of the desired state. It Check and confirm the numbers of resources that will be create. Use command:

   terraform plan

The list of all resources in stage of creation will appear and you can see all properties(arguments and attributs) of each resources

Step 6: Apply

Bring all desired state resources on life. It Launch and create all resources listed in the configuration files. The command to perform the task is:

   terraform apply -auto-approve

After typing this command the process of creation will start and you will be able to see which resources is on the way to be create and the time it taking to create.

At the end you will receive a prompt message showing all resources status: created, changed and the numbers of them.

Step 7: Review of resources

Go back on the console and check all actual state resources one by one to see. You will have

Instances running

Security groups

Step 8: Connect to the Controller

As we have our security group rule open on port SSH(22) we gonna use the CLI to connect to the controller instance. We must be on the folder that contains our private key pair. Then we go on the console select the instance hit on connect. you will have an image like the bellow:

Copy the Chmod command and paste on the CLI then type enter. Nothing will change. This command just chane the permission for SSH.

Copy the link second link and paste again CLI. Some instructions will run and you will be prompt to validate if you want to connect : type "yes" and you will have an image like bellow showing the connection to the server is been made.

The user date placed in the configuration file will install prerequisites needed to run Ansible such as Python3, amazon-linux extras and Ansible. take a look on the user data.

We can now change the static name or IP address to the name " controller " with the command

   $ sudo hostnamectl set-hostname controller

After you must exit and reconnect (ssh) again in order to have the new name appear in the path.

We now need to go on root to perform other command. We can do that with the command

   $ sudo -i

We can verify if Ansible was correctly install by typing command:

   $ ansible --version

There we will have this result

Step 9: Connect to all Hosts

We also, going to use the same process we used to connect to the controller meaning we will be SSH on each server.

Go to each server on the console select one by one and connect via option connect. In the tab Copy the Chmod command and paste on the CLI then type enter. Nothing will change. this command just chane the permission for SSH.

Copy the link second link and paste again CLI. Some instructions will run and you will be prompt to validate if you want to connect : type "yes" the process will now connect to the server. Linux2 and Ubuntu. You going to use the command bellow to change name for each server

   $ sudo hostnamectl set-hostname <name of the server>

For the Amazon Linux type : Linux-nodes1 and Linux-nodes2.
For Ubuntu type : ubuntu-nodes1 and ubuntu-nodes2.
Remember to exit and reconnect again to have the command take effect. Right after you must go to the root of the server by typing command

   $ sudo -i

At the end you will have an image with all servers CLI like bellow showing the connection to the server is been made.

Step 10: Generate & Copy Key Pair

Return to the controller to generate key pair that will be use to link the host server and clients or nodes server. We will generate a key pair which have a public and private key. You will have to copy the public and paste it in the folder named authorized_key of each nodes.

-Generate key pair with the command: must be on the root to perform this

   $ ssh-keygen -t rsa

Keep typing enter after all question asked. The command will generate public key (id_rsa.pub) and private key (id_rsa). Both will be in the folder name ".ssh" Enter the folder to see both keys. Type

   $ cd .ssh

Then the next command will list the contains of the folder

   $ ls -al

See the result on the image bellow

-The private key will stay in the controller and the public key will be copy and paste in the nodes.

   $ cat id_rsa.pub

Copy the content and go paste it in the authorized_keys of the nodes. You will have to go to each nodes be on the root and then enter the folder ".SSH " by typing command

   $ cd .ssh

You can list what is the contain of the folder with command

   $ ls -al

You will have a file name authorized_keys. You will have to enter the file by:

   $ vi authorized_keys

The file will have the private key already. So, you will have to type I (insert) then " fn + right arrow " to go to the end, then enter to go down and paste the copied text there. Lastly type Esc + :wq! To save the change. Do the same for all your nodes.

Here are images for all steps:

Step 11: Configuration on Controller

You can now return to the controller and follow the configuration of the nodes by copy and paste the nodes Ip address in order to create the link between controller and nodes. Make sure to be in the ".SSH " folder then from there type version command

   $ ansible --version

There will be a config file with destination /etc/ansible/ansible.cfg. You must enter in the Ansible folder

   $ cd /etc/

Then

   $ cd ansible

And this command to see the content of the folder.

   $ ls -al

There will be three files (ansilbe.cfg, hosts and roles). You must enter the files hosts to add all hosts meaning all private IP of all the nodes in the Ex2 collection section. If you group make sure to put the name of the group in brackets [ubuntu-nodes] and [linux-nodes] and down the public or private IP address of the nodes.

Enter the hosts file to perform all changes:

   $ vi hosts

Type i (insert) then copy/paste all IP address of nodes in the IP section of the file, Lastly type Esc : wq! To save the change.

You must create a folder on the root named " web " and you must drop the "index.html" inside the folder.

Step 12: Run Ansible Command

To test the connectivity you can try with one nodes or all nodes One nodes type

   $ ssh root@<private Ip placed on the hosts lists>.                   Ex: $ ssh root@10.0.1.10

You will be prompt to valid the connection so you will press "y" to confirm and the connection will go through. To logout type exit.

For all servers type:

   $ ansible -m ping all

Step 13: Review of Changes

After making sure all connectives are done between the controller and nodes. We have to return to the root and create a folder named "web" with the command

   $ mkdir web

Then enter the folder with the command

   $ cd web

Once you inside the folder you must create two files " index.html " and " playbook.yml "

As we have both files setup in the web folder. We will remain on the folder and we will use the Ansible command to perform all the requirements of the playbook file. Type command;

   $ ansible-playbook playbook.yml

the process will follow and you will have all the steps or plays written in the playbook been deploy. images will show what exactly are the outputs:

All tasks on the Linux nodes:

  • Upgrade nodes

  • Install latest Apache server

  • Start Apache

  • Enable Apache

  • Copy Index.html from source to destination

  • Install Git

The same tasks executed on Linux will also be done on Ubuntu nodes

Here is now the recap of all tasks done.

You can test the web page by copying any public Ip of nodes then paste it in the browser you will have this bellow result.

Step 14: Destroy

Destroy the terraform managed infrastructure meaning all resources created will be shut down. This action can be done with the command "terraform destroy"

   terraform destroy -auto-approve

At the end you will receive a prompt message showing all resources has been destroyed
