Three Methods for Launching Amazon Linux 2 and Ubuntu EC2 Instances with Docker and Jenkins installed

🚀 Overview:

This project aims to demonstrate three different approaches to launching Amazon Linux 2 and Ubuntu EC2 instances on AWS and installing Docker and Jenkins on them. The three methods include using AWS CloudFormation, Terraform, and direct Bash scripting with user data.

🔧 Problem Statement

This project demonstrates three distinct methods to deploy Amazon Linux 2 and Ubuntu EC2 instances with Docker and Jenkins installed. Each approach showcases different infrastructure-as-code and automation techniques commonly used in DevOps practices.

💽 Techonology Stack

The architecture consists of the following three tiers:

VPC: AWS VPC
EC2 Instances: AWS EC2
Containerization: Docker
Cl/CD: Jenkins
Scripting: Bashscript

📌 Architecture Diagram

                                      +-----------------------------+
                                      |         AWS Region          |
                                      |                             |
                                      | +-------------------------+ |
                                      | |       VPC               | |
                                      | |                         | |
                                      | | +-------------------+   | |
                                      | | | Availability Zone |   | |
                                      | | |         A         |   | |
                                      | | |                   |   | |
                                      | | | +-------------+   |   | |
                                      | | | |  Subnet A   |   |   | |
                                      | | | |             |   |   | |
                                      | | | | +--------+  |   |   | |
                                      | | | | | EC2     |  |   |   | |
                                      | | | | | Amazon  |  |   |   | |
                                      | | | | | Linux 2 |  |   |   | |
                                      | | | | +--------+  |   |   | |
                                      | | | +-------------+   |   | |
                                      | | +-------------------+   | |
                                      | |                         | |
                                      | | +-------------------+   | |
                                      | | | Availability Zone |   | |
                                      | | |         B         |   | |
                                      | | |                   |   | |
                                      | | | +-------------+   |   | |
                                      | | | |  Subnet B   |   |   | |
                                      | | | |             |   |   | |
                                      | | | | +--------+  |   |   | |
                                      | | | | | EC2     |  |   |   | |
                                      | | | | | Ubuntu  |  |   |   | |
                                      | | | | +--------+  |   |   | |
                                      | | | +-------------+   |   | |
                                      | | +-------------------+   | |
                                      | |                         | |
                                      | +-------------------------+ |
                                      |                             |
                                      +-----------------------------+

🌟 Project Requirements

Before you get started, make sure you have the following prerequisites in place:

AWS account with an IAM user credentials configured in.
An Infrastructure (VPC, Subnets, route table, Security groups, NACL...) ready to be use for the lab.
An Amazon Linux 2 and Ubuntu EC2 instance running for the part for the bash scripting
To install Jenkins on a server you must have minimum hardware requirements:

256 MB of RAM 1 GB of drive space (although 10 GB is a recommended minimum if running Jenkins as a Docker container) Recommended hardware configuration for a small team: 4 GB+ of RAM 50 GB+ of drive space
To install Jenkins on a server you must have minimum hardware requirements:

OS: 64-bit version of Ubuntu RAM: At least 2 GB, but Docker recommends more for larger deployments or resource-intensive applications Disk space: 100 GB of free space CPU: Sufficient amount, depending on the applications Kernel: 64-bit kernel with support for virtualization Virtualization: Support for KVM virtualization technology QEMU: Version 5.2 or later Init system: systemd init system Desktop environment: Gnome, KDE, or MATE Firewall: Firewall rulesets created with iptables or iptables6, and added to the DOCKER-USER chai.

📋 Table of Contents

I - AWS CloudFormation Template

Step 1: Description

Step 2: Instructions of deployment

Step 3: Results

Step 4: Clean up

II - Terraform Script

Step 1: Description

Step 2: Instructions of deployment

Step 3: Results

Step 4: Clean Up

III - Bash Script

Step 1: Description

Step 2: Instructions of deployment

Step 3: Results

Step 4: Clean Up

✨AWS CLOUDFORMATION TEMPLATE

Step 1: DESCRIPTION

AWS CloudFormation allows you to define your infrastructure as code. We will create a CloudFormation template that launches Amazon Linux 2 and Ubuntu EC2 instances and uses user data scripts to install Docker and Jenkins.

Step 2: INSTRUCTIONS OF DEPLOYMENT

Create a CloudFormation template

Use your VS Code to create both files "Linux_Docker_jenkins.yml" and "ubntu-docker-jenkins.yml"

Define the resources for Amazon Linux 2 and Ubuntu EC2 instances. Here Use the UserData property to specify a script that installs Docker and Jenkins.

Linux-Docker-Jenkins.yml

  AWSTemplateFormatVersion: '2010-09-09'

  Metadata:
   License: Apache-2.0
   Authors:
      Description: Joseph Mbatchou
   Description: " This template launches an amazon Linux 2 ec2 instance in a custom VPC, with an IAM assume role attached to it
                for SSM, then with the user data it will install Docker and Jenkins"

  Parameters:
    InstanceType:
      Description: EC2 instance type.
      Type: String
      AllowedValues:
        - t2.nano
        - t2.micro
        - t2.small
        - t2.medium
        - t2.large
    KeyName:
      Description: Name of an existing EC2 key pair for SSH access to the EC2 instance.
      Type: AWS::EC2::KeyPair::KeyName
    SSHLocation:
      Description: The IP address range that can be used to SSH to the EC2 instances
      Type: String
      MinLength: '9'
      MaxLength: '18'
      AllowedPattern: "(\\d{1,3})\\.(\\d{1,3})\\.(\\d{1,3})\\.(\\d{1,3})/(\\d{1,2})" # IP Address
      ConstraintDescription: must be a valid IP CIDR range of the form x.x.x.x/x.
    ImageId:
      Type: AWS::SSM::Parameter::Value<AWS::EC2::Image::Id>
      Default: /aws/service/ami-amazon-linux-latest/amzn2-ami-hvm-x86_64-gp2
    VpcId:
      Type: AWS::EC2::VPC::Id
      Description: Select an existing VPC
    SubnetId:
      Type: AWS::EC2::Subnet::Id
      Description: Select an existing subnet within the selected VPC
  Resources:
    IamRole:
      Type: 'AWS::IAM::Role'
      Properties:
        RoleName: Ec2RoleForSSM
        Description: EC2 IAM role for SSM access
        AssumeRolePolicyDocument:
          Version: '2012-10-17'
          Statement:
            - Effect: Allow
              Principal:
                Service:
                  - ec2.amazonaws.com
              Action:
                - 'sts:AssumeRole'
        Path: /
        ManagedPolicyArns:
          - 'arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore'
    Ec2InstanceProfile:
      Type: 'AWS::IAM::InstanceProfile'
      Properties:
        InstanceProfileName: Ec2RoleForSSM
        Path: /
        Roles:
          - Ref: IamRole
    WebServer:
      Type: AWS::EC2::Instance
      Properties:
        IamInstanceProfile: !Ref Ec2InstanceProfile
        ImageId: !Ref ImageId
        InstanceType: !Ref InstanceType
        KeyName: !Ref KeyName
        NetworkInterfaces:
        - AssociatePublicIpAddress: "true"
          DeviceIndex: "0"
          GroupSet:
            - !Ref WebServerSecurityGroup
          SubnetId: !Ref SubnetId
        UserData:
          Fn::Base64: !Sub |
            #!/bin/bash
            sudo yum update -y
            sudo yum install python3-pip
            sudo amazon-linux-extras install docker
            sudo yum install -y docker
            sudo service docker start
            sudo systemctl enable docker
            sudo systemctl restart docker
            sudo usermod -aG docker ec2-user
            sudo yum update -y
            sudo sudo wget -O /etc/yum.repos.d/jenkins.repo \
            https://pkg.jenkins.io/redhat-stable/jenkins.repo
            sudo rpm --import https://pkg.jenkins.io/redhat-stable/jenkins.io-2023.key
            sudo yum upgrade
            sudo yum install java-17-amazon-corretto -y
            sudo yum install jenkins -y
            sudo systemctl start jenkins
            sudo systemctl enable jenkins
            sudo systemctl restart jenkins
            sudo usermod -aG jenkins ec2-user
            sudo reboot

        Tags:
         - Key: Name
           Value: Linux-Docker-Jenkins-Server
    WebServerSecurityGroup:
      Type: AWS::EC2::SecurityGroup
      Properties:
        GroupDescription: 'Enable HTTP access via port 80 SSH access'
        VpcId: !Ref VpcId
        SecurityGroupIngress:
          - CidrIp: 0.0.0.0/0
            FromPort: 8080
            IpProtocol: tcp
            ToPort: 8080
          - CidrIp: !Ref SSHLocation
            FromPort: 22
            IpProtocol: tcp
            ToPort: 22
          - CidrIp: 0.0.0.0/0
            FromPort: 80
            IpProtocol: tcp
            ToPort: 80

  Outputs:
    InstanceId:
      Description: ID of the EC2 instance
      Value: !Ref WebServer
    PublicDNS:
      Description: Public DNS name of the EC2 instance
      Value: !GetAtt WebServer.PublicDnsName
    PublicIP:
      Description: Public IP address of the EC2 instance
      Value: !GetAtt WebServer.PublicIp

ubuntu-docker-jenkins.yml

AWSTemplateFormatVersion: '2010-09-09'

Metadata:
  License: Apache-2.0
  Authors:
    Description: Joseph Mbatchou  # The writer of this template
  Description: " This template launches an ubuntu ec2 instance in a custom VPC, with an IAM assume role attached to it
              for SSM, then with the user data it will install Docker and Jenkins"

Parameters:
  InstanceType:
    Description: EC2 instance type.
    Type: String
    AllowedValues:
      - t2.nano
      - t2.micro
      - t2.small
      - t2.medium
      - t2.large
  KeyName:
    Description: Name of an existing EC2 key pair for SSH access to the EC2 instance.
    Type: AWS::EC2::KeyPair::KeyName
  SSHLocation:
    Description: Place to enter your IP address. The IP address range that can be used to SSH to the EC2 instances
    Type: String
    MinLength: '9'
    MaxLength: '18'
    AllowedPattern: "(\\d{1,3})\\.(\\d{1,3})\\.(\\d{1,3})\\.(\\d{1,3})/(\\d{1,2})"
    ConstraintDescription: must be a valid IP CIDR range of the form x.x.x.x/x.
  ImageId:
    Type: AWS::SSM::Parameter::Value<AWS::EC2::Image::Id>
    Default: '/aws/service/canonical/ubuntu/server/jammy/stable/current/amd64/hvm/ebs-gp2/ami-id'
  VpcId:
    Type: AWS::EC2::VPC::Id
    Description: Select an existing VPC
  SubnetIds:
    Type: AWS::EC2::Subnet::Id
    Description: Select at least one subnet within the selected VPC

Resources:
  IamRole:
    Type: 'AWS::IAM::Role'
    Properties:
      RoleName: !Sub "${AWS::StackName}-Ec2RoleForSSM"
      Description: EC2 IAM role for SSM access
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - Effect: Allow
            Principal:
              Service:
                - ec2.amazonaws.com
            Action:
              - 'sts:AssumeRole'
      Path: /
      ManagedPolicyArns:
        - 'arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore'

  Ec2InstanceProfile:
    Type: 'AWS::IAM::InstanceProfile'
    Properties:
      InstanceProfileName: !Sub "${AWS::StackName}-Ec2RoleForSSM"
      Path: /
      Roles:
        - !Ref IamRole

  WebServer:
    Type: AWS::EC2::Instance
    Properties:
      IamInstanceProfile: !Ref Ec2InstanceProfile
      ImageId: !Ref ImageId
      InstanceType: !Ref InstanceType
      KeyName: !Ref KeyName
      NetworkInterfaces:
        - AssociatePublicIpAddress: "true"
          DeviceIndex: "0"
          GroupSet:
            - !Ref WebServerSecurityGroup
          SubnetId: !Ref SubnetIds
      UserData:
        Fn::Base64: !Sub |
          #!/bin/bash
          sudo apt-get update
          sudo apt-get install -y ca-certificates curl gnupg
          sudo install -m 0755 -d /etc/apt/keyrings
          curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
          sudo chmod a+r /etc/apt/keyrings/docker.gpg
          echo \
             "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu \
             $(. /etc/os-release && echo "$VERSION_CODENAME") stable" | \
             sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
          sudo apt-get update
          sudo apt-get install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
          sudo systemctl start docker.service
          sudo systemctl enable docker.service
          sudo usermod -aG docker ubuntu
          sudo apt-get update -y
          sudo apt-get install openjdk-17-jdk -y
          sudo curl -fsSL https://pkg.jenkins.io/debian-stable/jenkins.io-2023.key | sudo tee   /usr/share/keyrings/jenkins-keyring.asc > /dev/null
          sudo echo deb [signed-by=/usr/share/keyrings/jenkins-keyring.asc]   https://pkg.jenkins.io/debian-stable binary/ | sudo tee   /etc/apt/sources.list.d/jenkins.list > /dev/null
          sudo apt-get update
          sudo apt-get install jenkins -y
          sudo systemctl start jenkins
          sudo systemctl enable jenkins
          sudo usermod -aG jenkins ubuntu
          sudo ufw allow 8080
          sudo ufw allow OpenSSH
          sudo ufw enable
      Tags:
        - Key: Name
          Value: Ubuntu-Docker-jenkins-server

  WebServerSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: 'Enable HTTP access via port 80 SSH access'
      VpcId: !Ref VpcId
      SecurityGroupIngress:
        - CidrIp: 0.0.0.0/0
          FromPort: 8080
          IpProtocol: tcp
          ToPort: 8080
        - CidrIp: !Ref SSHLocation
          FromPort: 22
          IpProtocol: tcp
          ToPort: 22
        - CidrIp: 0.0.0.0/0
          FromPort: 80
          IpProtocol: tcp
          ToPort: 80

Outputs:
  InstanceId:
    Description: ID of the EC2 instance
    Value: !Ref WebServer
  PublicDNS:
    Description: Public DNS name of the EC2 instance
    Value: !GetAtt WebServer.PublicDnsName
  PublicIP:
    Description: Public IP address of the EC2 instance
    Value: !GetAtt WebServer.PublicIp

Deploy the stack using the AWS Management Console.

On the console you must open CloudFormation option then hit on "Create Stack"

Linux-stack

ubuntu stack

After launching both stacks you will get the complete stage

Step 3: RESULTS

As result you will get first both instances running in the console

After connecting to each servers via Session manager or SSH you can check status and version of each application installed.

Linux instance

ubuntu instance

Step 4: CLEAN UP

You can clean up all resources created by just delete them via the CloudFormation stack . You just need to go back in the CloudFormation window select the stack and hit delete button till you get to the message saying "Delete Complete" .

✨TERRAFORM SCRIPT

Step 1: DESCRIPTION

Terraform is an open-source infrastructure as code software tool. We will create Terraform scripts to launch Amazon Linux 2 and Ubuntu EC2 instances and use user data to install Docker and Jenkins.

Step 2: INSTRUCTIONS OF DEPLOYMENT

Create a Terraform script

Here you will have to create both (Linux-main.tf and ubuntu-main.tf) files and you will put each of them in a folder.

Define the resources for Amazon Linux 2 and Ubuntu EC2 instances. Use the UserData property to specify a script that installs Docker and Jenkins.

Here are the contains of each files

Linux-main.tf

  terraform {
    required_providers {
      aws = {
        source  = "hashicorp/aws"
        version = "~> 4.0"
      }
    }

  }
  variable "aws_region" {
    type        = string
    description = "region where to launch"
    default = "us-west-2"
  }
  variable "instance_type" {
    type        = string
    description = "instance type of the instance"
    default = "ansible-key"
  }

  variable "key_name" {
    type        = string
    description = "rkey name of the instance"
    default = "t2.micro"
  }
  #Configure the AWS Provider
  provider "aws" {
    region = var.aws_region
  }# Data source for latest Amazon Linux 2 AMI
  data "aws_ami" "amazon_linux_2" {
    most_recent = true
    owners      = ["amazon"]

    filter {
      name   = "name"
      values = ["amzn2-ami-hvm-*-x86_64-gp2"]
    }
  }
  data "aws_vpc" "custom_vpc" {
    filter {
      name   = "tag:Name"
      values = ["c@licost-vpc"] # Replace with your VPC's name tag
    }
  }
  data "aws_subnet" "custom_subnet" {
    vpc_id = data.aws_vpc.custom_vpc.id

    filter {
      name   = "tag:Name"
      values = ["c@licost-subnet-public2-us-west-2b"] # Replace with your subnet's name tag
    }
  }

  # IAM Role
  resource "aws_iam_role" "ec2_ssm_role" {
    name = "Ec2RoleForSSM"
    assume_role_policy = jsonencode({
      Version = "2012-10-17"
      Statement = [
        {
          Action = "sts:AssumeRole"
          Effect = "Allow"
          Principal = {
            Service = "ec2.amazonaws.com"
          }
        }
      ]
    })
  }

  resource "aws_iam_role_policy_attachment" "ssm_policy_attachment" {
    role       = aws_iam_role.ec2_ssm_role.name
    policy_arn = "arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore"
  }

  resource "aws_iam_instance_profile" "ec2_profile" {
    name = "Ec2RoleForSSM"
    role = aws_iam_role.ec2_ssm_role.name
  }

  # Security Group
  resource "aws_security_group" "web_server_sg" {
    name        = "WebServerSecurityGroup"
    description = "Enable HTTP access via port 80 SSH access"
    vpc_id      = data.aws_vpc.custom_vpc.id

    ingress {
      from_port   = 8080
      to_port     = 8080
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    ingress {
      from_port   = 22
      to_port     = 22
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    ingress {
      from_port   = 80
      to_port     = 80
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    egress {
      from_port   = 0
      to_port     = 0
      protocol    = "-1"
      cidr_blocks = ["0.0.0.0/0"]
    }
  }

  # EC2 Instance
  resource "aws_instance" "web_server" {
    ami                    = data.aws_ami.amazon_linux_2.id
    instance_type          = var.instance_type
    key_name               = var.key_name
    subnet_id              = data.aws_subnet.custom_subnet.id
    vpc_security_group_ids = [aws_security_group.web_server_sg.id]
    iam_instance_profile   = aws_iam_instance_profile.ec2_profile.name
    associate_public_ip_address = "true"

    user_data = base64encode(<<-EOF
      #!/bin/bash
      sudo yum update -y
      sudo yum install python3-pip
      sudo amazon-linux-extras install docker
      sudo yum install -y docker
      sudo service docker start
      sudo systemctl enable docker
      sudo systemctl restart docker
      sudo usermod -aG docker ec2-user
      sudo yum update -y
      sudo sudo wget -O /etc/yum.repos.d/jenkins.repo \
      https://pkg.jenkins.io/redhat-stable/jenkins.repo
      sudo rpm --import https://pkg.jenkins.io/redhat-stable/jenkins.io-2023.key
      sudo yum upgrade
      sudo yum install java-17-amazon-corretto -y
      sudo yum install jenkins -y
      sudo systemctl start jenkins
      sudo systemctl enable jenkins
      sudo systemctl restart jenkins
      sudo usermod -aG jenkins ec2-user
      sudo reboot
    EOF
    )

    tags = {
      Name = "Linux-Docker-Jenkins-server"
    }
  }
  output "instance_id" {
    description = "ID of the EC2 instance"
    value       = aws_instance.web_server.id
  }

  output "public_dns" {
    description = "Public DNS name of the EC2 instance"
    value       = aws_instance.web_server.public_dns
  }

  output "public_ip" {
    description = "Public IP address of the EC2 instance"
    value       = aws_instance.web_server.public_ip
  }

ubuntu-main.tf

  terraform {
    required_providers {
      aws = {
        source  = "hashicorp/aws"
        version = "~> 4.0"
      }
    }
  }
  #Configure the AWS Provider
  provider "aws" {
    region = var.aws_region
  }
  variable "aws_region" {
    type        = string
    description = "region where to launch"
    default = "us-west-2"
  }
  variable "instance_type" {
    type        = string
    description = "instance type of the instance"
    default = "ansible-key"
  }

  variable "key_name" {
    type        = string
    description = "rkey name of the instance"
    default = "t2.micro"
  }

  #Data source for latest Amazon Linux 2 AMI
  data "aws_ami" "ubuntu" {
    most_recent = true
    owners      = ["amazon"]

    filter {
      name   = "name"
      values = ["ubuntu/images/hvm-ssd/ubuntu-jammy-22.04-amd64-server-*"]
    }
  }
  data "aws_vpc" "custom_vpc" {
    filter {
      name   = "tag:Name"
      values = ["c@licost-vpc"] # Replace with your VPC's name tag
    }
  }
  data "aws_subnet" "custom_subnet" {
    vpc_id = data.aws_vpc.custom_vpc.id

    filter {
      name   = "tag:Name"
      values = ["c@licost-subnet-public2-us-west-2b"] # Replace with your subnet's name tag
    }
  }

  # IAM Role
  resource "aws_iam_role" "ec2_ssm_role" {
    name = "Ec2RoleForSSM"
    assume_role_policy = jsonencode({
      Version = "2012-10-17"
      Statement = [
        {
          Action = "sts:AssumeRole"
          Effect = "Allow"
          Principal = {
            Service = "ec2.amazonaws.com"
          }
        }
      ]
    })
  }

  resource "aws_iam_role_policy_attachment" "ssm_policy_attachment" {
    role       = aws_iam_role.ec2_ssm_role.name
    policy_arn = "arn:aws:iam::aws:policy/AmazonSSMManagedInstanceCore"
  }

  resource "aws_iam_instance_profile" "ec2_profile" {
    name = "Ec2RoleForSSM"
    role = aws_iam_role.ec2_ssm_role.name
  }

  # Security Group
  resource "aws_security_group" "web_server_sg" {
    name        = "WebServerSecurityGroup"
    description = "Enable HTTP access via port 80 SSH access"
    vpc_id      = data.aws_vpc.custom_vpc.id

    ingress {
      from_port   = 8080
      to_port     = 8080
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    ingress {
      from_port   = 22
      to_port     = 22
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    ingress {
      from_port   = 80
      to_port     = 80
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    egress {
      from_port   = 0
      to_port     = 0
      protocol    = "-1"
      cidr_blocks = ["0.0.0.0/0"]
    }
  }

  # EC2 Instance
  resource "aws_instance" "web_server" {
    ami                         = data.aws_ami.ubuntu.id
    instance_type               = var.instance_type
    key_name                    = var.key_name
    subnet_id                   = data.aws_subnet.custom_subnet.id
    vpc_security_group_ids      = [aws_security_group.web_server_sg.id]
    iam_instance_profile        = aws_iam_instance_profile.ec2_profile.name
    associate_public_ip_address = "true"

    user_data = base64encode(<<-EOF
      #!/bin/bash
      sudo apt-get update
      sudo apt-get install -y ca-certificates curl gnupg
      sudo install -m 0755 -d /etc/apt/keyrings
      curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
      sudo chmod a+r /etc/apt/keyrings/docker.gpg
      echo \
         "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu \
         $(. /etc/os-release && echo "$VERSION_CODENAME") stable" | \
         sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
      sudo apt-get update
      sudo apt-get install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
      sudo systemctl start docker.service
      sudo systemctl enable docker.service
      sudo usermod -aG docker ubuntu
      sudo apt-get update -y
      sudo apt-get install openjdk-17-jdk -y
      sudo curl -fsSL https://pkg.jenkins.io/debian-stable/jenkins.io-2023.key | sudo tee   /usr/share/keyrings/jenkins-keyring.asc > /dev/null
      sudo echo deb [signed-by=/usr/share/keyrings/jenkins-keyring.asc]   https://pkg.jenkins.io/debian-stable binary/ | sudo tee   /etc/apt/sources.list.d/jenkins.list > /dev/null
      sudo apt-get update
      sudo apt-get install jenkins -y
      sudo systemctl start jenkins
      sudo systemctl enable jenkins
      sudo usermod -aG jenkins ubuntu
      sudo ufw allow 8080
      sudo ufw allow OpenSSH
      sudo ufw enable
    EOF
    )

    tags = {
      Name = "Ubuntu-Docker-jenkins-server"
    }
  }
  output "instance_id" {
    description = "ID of the EC2 instance"
    value       = aws_instance.web_server.id
  }

  output "public_dns" {
    description = "Public DNS name of the EC2 instance"
    value       = aws_instance.web_server.public_dns
  }

  output "public_ip" {
    description = "Public IP address of the EC2 instance"
    value       = aws_instance.web_server.public_ip
  }

Step 3: RESULTS

After putting each files in a folder we have to go through the process of running terraform

Initialise the folder

    terraform init

Check the correct syntax of the file

    terraform fmt

Valid the status of the file

    terraform validate

Plan to see which resources will be create

    terraform plan

Create the resources with command

    terraform apply

After all this we will get to the result images

Linux instance

In the console you have

Ubutntu

In the console

After SSM connect to each instances we have the result of different version

For Linux instance
For Ubuntu instance

Step 4: CLEAN UP

Use the command destroy to delete all the infrastructures
```
  terraform destroy
```

For the Linux instance

For the ubuntu instance

✨BASH SCRIPT

Step 1: DESCRIPTION

A Bash script can be used to manually launch EC2 instances and configure them using the AWS CLI. We will write a Bash script that launches Amazon Linux 2 and Ubuntu EC2 instances and uses user data to install Docker and Jenkins.

Step 2: INSTRUCTIONS OF DEPLOYMENT

Create a Bash script (launch-instances.sh). This with contains the process of creating both Amazon linux and Ubuntu EC2 instances. The script included default value you can customize to your values.

  #!/bin/bash

  # Variables
  REGION="us-west-2"
  INSTANCE_TYPE="t2.micro"
  KEY_NAME="ansible-key"
  SECURITY_GROUP_ID=$(aws ec2 describe-security-groups --filters Name=group-name,Values=DevOps-SG --query 'SecurityGroups[0].GroupId' --output text --region $REGION)

  # Subnet IDs - replace these with your actual subnet IDs
  SUBNET_ID_1="subnet-0afe31980b7b724ac"
  SUBNET_ID_2="subnet-099fca76d17b2fd4f"

  # Launch Amazon Linux 2 Instance
  aws ec2 run-instances \
      --image-id ami-0648742c7600c103f \
      --count 1 \
      --instance-type $INSTANCE_TYPE \
      --associate-public-ip-address \
      --key-name $KEY_NAME \
      --security-group-ids $SECURITY_GROUP_ID \
      --subnet-id $SUBNET_ID_1 \
      --region $REGION \
      --user-data file:///users/josephmbatchou/amazon-linux-user-data.sh \
      --tag-specifications 'ResourceType=instance,Tags=[{Key=Name,Value=AmazonLinux2-Instance},{Key=OS,Value=AmazonLinux2}]'

  # Launch Ubuntu Instance
  aws ec2 run-instances \
      --image-id ami-0075013580f6322a1 \
      --count 1 \
      --instance-type $INSTANCE_TYPE \
      --key-name $KEY_NAME \
      --associate-public-ip-address \
      --security-group-ids $SECURITY_GROUP_ID \
      --subnet-id $SUBNET_ID_2 \
      --region $REGION \
      --user-data file:///users/josephmbatchou/ubuntu-user-data.sh \
      --tag-specifications 'ResourceType=instance,Tags=[{Key=Name,Value=Ubuntu-Instance},{Key=OS,Value=Ubuntu}]'

Create both Bash script user data scripts to install Docker and Jenkins on the instances. Files are "amazon-linux-user-data.sh" and "ubuntu-user-data.sh"

amazon-linux-user-data.sh

#!/bin/bash

# install Jenkins
sudo yum update -y
sudo sudo wget -O /etc/yum.repos.d/jenkins.repo \
    https://pkg.jenkins.io/redhat-stable/jenkins.repo
sudo rpm --import https://pkg.jenkins.io/redhat-stable/jenkins.io-2023.key
sudo yum upgrade
sudo yum install java-17-amazon-corretto -y
sudo yum install jenkins -y
sudo systemctl start jenkins
sudo systemctl enable jenkins
sudo systemctl restart jenkins
sudo usermod -aG jenkins ec2-user

#install Docker
sudo yum update -y
sudo yum install python3-pip
sudo amazon-linux-extras install docker
sudo yum install -y docker
sudo service docker start
sudo systemctl enable docker
sudo systemctl restart docker
sudo usermod -aG docker ec2-user

ubuntu-user-data.sh

#!/bin/bash

#Install Jenkins
sudo apt-get update -y
sudo apt-get install openjdk-17-jdk -y
sudo curl -fsSL https://pkg.jenkins.io/debian-stable/jenkins.io-2023.key | sudo tee   /usr/share/keyrings/jenkins-keyring.asc > /dev/null
sudo echo deb [signed-by=/usr/share/keyrings/jenkins-keyring.asc]   https://pkg.jenkins.io/debian-stable binary/ | sudo tee   /etc/apt/sources.list.d/jenkins.list > /dev/null
sudo apt-get update
sudo apt-get install jenkins -y
sudo systemctl start jenkins
sudo systemctl enable jenkins
sudo usermod -aG jenkins ubuntu
sudo ufw allow 8080
sudo ufw allow OpenSSH
sudo ufw enabley

#install Docker
sudo apt-get update
sudo apt-get install -y ca-certificates curl gnupg
sudo install -m 0755 -d /etc/apt/keyrings
curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
sudo chmod a+r /etc/apt/keyrings/docker.gpg
echo \
   "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu \
   $(. /etc/os-release && echo "$VERSION_CODENAME") stable" | \
   sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
sudo apt-get update
sudo apt-get install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
sudo systemctl start docker.service
sudo systemctl enable docker.service
sudo usermod -aG docker ubuntu

Use the AWS CLI to launch Amazon Linux 2 and Ubuntu EC2 instances:

In order to run the script to provision the infrastructure by using CLI you must be in the prompt where your AWS CLI is configure and in the default region. Our Default region here is "us-west-2" You can verify this by using command

aws configure

Once you are set up you will have to make each script to be executable by changing modification command.

chmod +x launch-instances.sh
chmod +x amazon-linux-user-data.sh
chmod +x ubuntu-user-data.sh

As the both user data script are incorporated in the instance script you will only have to run the launch instance script with the command

./launch-instance.sh

The process of launching resources will follow and you will get results succeeded.

Linux instance

Ubuntu instance

step 3: RESULTS

You can go to the console and see that two instances were created and by connecting to them via SSH you will check for tools installed.

As you will ssh to each instances you will now check for each applications version to confirm the installation.

Linux instance

Ubuntu instance

Step 4: CLEAN UP

To delete both instances you can only check for each instances Id and use command terminate-instance to destroy them.

aws ec2 terminate-instances --instance-ids <instance-id>

By using the command with the right instances id you will terminated the both instances.

📌 Conclusion

This project showcases three different approaches to launching and configuring EC2 instances with Docker and Jenkins. Each method has its advantages and can be chosen based on specific requirements and preferences. The use of infrastructure as code tools like CloudFormation and Terraform ensures reproducibility and ease of management, while Bash scripting provides flexibility and simplicity.

🤝 Contributing

Your perspective is valuable! Whether you see potential for improvement or appreciate what's already here, your contributions are welcomed and appreciated. Thank you for considering joining us in making this project even better. Feel free to follow me for updates on this project and others, and to explore opportunities for collaboration. Together, we can create something amazing!

📄 License

This project is licensed under the Joebaho Cloud License

Three ways of launching Amazon Linux 2 and Ubuntu Ec2 instances and install Docker and Jenkins on them

Comments (2)

More from this blog

Automated Multi-Region Disaster Recovery on AWS with Terraform

Terraform: Mount S3 Bucket on EC2 (Ubuntu) using s3fs‑fuse

GitOps-Powered EKS: Automating Kubernetes Deployments with Terraform, ArgoCD, and Monitoring Tools accessible via Load balancer

🚀 Automating Scalable Infrastructure with Terraform & Ansible Dynamic Inventory

Web Application Deployment on AWS Using Terraform, NGINX and Bash Scripting

Three Methods for Launching Amazon Linux 2 and Ubuntu EC2 Instances with Docker and Jenkins installed

🚀 Overview:

🔧 Problem Statement

💽 Techonology Stack

📌 Architecture Diagram

🌟 Project Requirements

📋 Table of Contents

✨AWS CLOUDFORMATION TEMPLATE

Step 1: DESCRIPTION

Step 2: INSTRUCTIONS OF DEPLOYMENT

✨TERRAFORM SCRIPT

Step 1: DESCRIPTION

Step 2: INSTRUCTIONS OF DEPLOYMENT

✨BASH SCRIPT

Step 1: DESCRIPTION

Step 2: INSTRUCTIONS OF DEPLOYMENT

📌 Conclusion

🤝 Contributing

📄 License

Command Palette

Comments (2)

More from this blog

Three Methods for Launching Amazon Linux 2 and Ubuntu EC2 Instances with Docker and Jenkins installed

🚀 Overview:

🔧 Problem Statement

💽 Techonology Stack

📌 Architecture Diagram

🌟 Project Requirements

📋 Table of Contents

✨AWS CLOUDFORMATION TEMPLATE

Step 1: DESCRIPTION

Step 2: INSTRUCTIONS OF DEPLOYMENT

✨TERRAFORM SCRIPT

Step 1: DESCRIPTION

Step 2: INSTRUCTIONS OF DEPLOYMENT

✨BASH SCRIPT

Step 1: DESCRIPTION

Step 2: INSTRUCTIONS OF DEPLOYMENT

📌 Conclusion

🤝 Contributing

📄 License
